Average Life Remaining - UNDERCARRIAGE Links 90%Bottom rollers 50%Carrier rollers 80%Segments 90%Pads 90%Idlers 80%
Notes - UNDERCARRIAGE System OneSee photosMachine has had new segments and track grps installed at some point and time
Track Shoes Width / Type 22”
Pins & Bushings Turned? No
Guiding Guard - Left Good
Guiding Guard - Right Good
Track Frame - Left Good
Track Frame - Right Good
Carrier Rollers Front
LEFT measurement 162mm
RIGHT measurement 162mm
Carrier Rollers Rear
LEFT measurement 162mm
RIGHT measurement 162mm
Idlers Front
LEFT measurement 43mm
RIGHT measurement 43mm
Links
LEFT measurement 107mm
RIGHT measurement 107mm
Track Roller 5
LEFT measurement 26mm
RIGHT measurement 26mm
Track Roller 6
LEFT measurement 26mm
RIGHT measurement 26mm
Track Shoe Grouser Height
LEFT measurement 55mm
RIGHT measurement 55mm
