Pins & Bushings Turned? No
Link / Brand / Part Number Cat 235-2529H
Track Shoes Width / Type 26 inches
Guiding Guard - Left Good
Guiding Guard - Right Good
Track Frame - Left Good
Track Frame - Right Good
Carrier Rollers Front
LEFT measurement 6.02
RIGHT measurement 5.83
Idlers Front
LEFT measurement 1.56
RIGHT measurement 1.68
Links
LEFT measurement 4.16
RIGHT measurement 4.05
Pins & Bushings (External)
LEFT measurement 2.24
RIGHT measurement 2.23
Pins & Bushings (Internal)
LEFT measurement 29.80
RIGHT measurement 29.80
Track Roller 1
LEFT measurement 6.22
RIGHT measurement 6.18
Track Roller 2
LEFT measurement 6.30
RIGHT measurement 6.34
Track Roller 3
LEFT measurement 6.34
RIGHT measurement 6.38
Track Roller 4
LEFT measurement 6.29
RIGHT measurement 6.39
Track Roller 5
LEFT measurement 6.26
RIGHT measurement 6.33
Track Shoe Grouser Height
LEFT measurement 1.61
RIGHT measurement 1.70
